Description
Amplifier Description
The DC-CS1000/4 is a compact series amplifier capable of making 1,000 watts. Its High power 4 Channel amplifier. It has 4awg inputs and onboard clipping lights. Designed to make more power in less space.
Output Power (RMS)
4 ohm 150Wx4 @ 14.4 Volts
2 ohm 240Wx4 @ 14.4 Volts
4ohm rms bridged power : 500W x 2
Key Features
• 2 ohm stable
• Variable low pass filter
• Variable High pass filter
• Full Range Output
• 9-16 Volts Capable
• Onboard clip light
Full Specs:
| DC Amp Model: | DC-CS1000/4 |
|---|---|
| Input Sensitivity | 6V~0.2V |
| Frequency Response | 10Hz~31KHz |
| 24dB / Octave Crossover | YES |
| High Pass | 50Hz ~ 5ooHz |
| Low Pass | 50Hz ~ 5ooHz |
| Crossover Selector Switch | HPF / FULL / LP |
| Remote Control | No |
| Signal to Noise Ratio | dB105 |
| Damping Factor | 100< |
| THD @ 4ohms | Less than 0.1% |
| Fuse Rating | External 100 amp |
| LED Status Lights | Power / Protect / Clip |
| Heatsink Length | 9.44"/240mm |
| Heatsink Width | 4.72"/120mm |
| Heatsink Height | 1.96"/50.0mm |
