7.5k 7500 watt Mono Block Amplifier
Couldn't load pickup availability
About the Product
DC Audio 7.5k Amplifier
The 7.5k competition series amplifier is rated as a 7500 watt mono block. It is a linkable amp and designed to run a 1 ohm per amp or 2 ohms when linked for up to 18,400 watts from a pair. It comes with a bass knob.
Output Power (RMS):
- 2,000x1 @ 4 ohms 14.4 volts
- 4,400x1 @ 2 ohms 14.4 volts
- 7,500x1 @ 1 ohms 14.4 volts
- 15,000x1 @ 2 ohm 14.4 volts LINKED
- 8,600x1 @ 1 ohm 16.0 volts
- 17,200x1 @ 2 ohm 16.0 volts LINKED
- 9,200x1 @ 1 ohm 18.0 volts
- 18,400x1 @ 2 ohm 18.0 volts LINKED
Key Features:
- 1 ohm stable
- Variable low pass filter
- Variable subsonic filter
- Variable bass boost
- RCA Pass Thru
- Linkable
- Wired remote control
- 8awg Speaker Terminals
- Dual 1/0awg Power and Ground Inputs
Full Specs:
DC Amp Model: | 7.5k |
---|---|
Input Sensitivity | 6V~0.2V |
Frequency Response | 20Hz~250Hz |
24dB / Octave Crossover | YES |
Low Pass | 35Hz ~ 250Hz |
Subsonic Filter | 10Hz-50hz |
Bass Boost @45hz | 0 ~ 9db |
Phase Shift | 0 ~ 180 |
Remote Control | Yes |
Clip Indicator | No |
Signal to Noise Ratio | dB100 |
Damping Factor | 250< |
THD @ 4ohms | Less than 0.1% |
Fuse Rating | External 400 amp x 2 |
LED Status Lights | Power and Protect |
Master/Slave | YES |
Heatsink Length | 25.596"/820mm |
Heatsink Width | 11.5"/292mm |
Heatsink Height | 2.6"/66mm |
