DC 1.2k Amplifier
The 1.2kw competition series amplifier is a 1,200 watt rated mono block. It is capable of running up to 16 volts for up to 1500 watts. It is a linkable amp and designed to run a 1 ohm per amp or 2 ohms when strapped for up to 3000 watts from a pair.
Output Power (RMS):
- 4 ohm 350Wx1 @ 14.4 Volts
- 2 ohm 700Wx1 @ 14.4 Volts
- 1 ohm mono 1200x1 @ 14.4 Volts
- 1 ohm mono 1500x1 @ 16.0 Volts
Key Features:
- 1 ohm stable
- Variable low pass filter
- Variable subsonic filter
- Variable bass boost
- Wired Bass Knob remote control
- RCA Pass Thru
- Linkable
Full Specs:
| DC Amp Model: | 1.2k |
|---|---|
| Input Sensitivity | 6V~0.2V |
| Frequency Response | 15Hz~270Hz |
| 24dB / Octave Crossover | YES |
| Low Pass | 35Hz ~ 250Hz |
| Subsonic Filter | 10Hz-50hz |
| Remote Control | Yes |
| Signal to Noise Ratio | dB100 |
| Damping Factor | 100< |
| THD @ 4ohms | Less than 0.1% |
| Fuse Rating | External 120 amp |
| LED Status Lights | Power and Protect |
| Heatsink Length | 16.60"/419mm |
| Heatsink Width | 9.38"/238mm |
| Heatsink Height | 2.35"/59.6mm |
